Limit Hits to an Attack Window in BBC Micro BASIC

A sword swing can overlap the same enemy for several updates. That should not automatically mean several hits. Give the attack an active interval and remember which targets it has already hit; the collision routine can still report contact every time.

Include and initialise

Include routines.bas, reserving lines 3000–3240, public H/O/M/F/A/B/T/C/N and private P. Call 3000 at an intended reset boundary. It clears all public fields. Keep a STOP, END or jump before the helper so ordinary execution cannot fall into it. Call 3100 for each candidate contact.

F is the attack frame; A and B are the start and exclusive end of its active interval. T is a stable target index from zero to seven. C is a contact flag and N signals a new attack; any nonzero byte means true. M is the retained eight-target hit mask. H reports a newly accepted hit and O reports valid inputs.

Reusable numbered routines

3000 LET H=0: LET O=0: LET M=0: LET F=0: LET A=0: LET B=0: LET T=0: LET C=0: LET N=0: RETURN
3100 LET H=0: LET O=0
3110 IF M<0 OR M>255 OR M<>INT (M) THEN RETURN
3120 IF F<0 OR F>255 OR F<>INT (F) THEN RETURN
3130 IF A<0 OR A>255 OR A<>INT (A) THEN RETURN
3140 IF B<0 OR B>255 OR B<>INT (B) THEN RETURN
3150 IF T<0 OR T>7 OR T<>INT (T) THEN RETURN
3160 IF C<0 OR C>255 OR C<>INT (C) THEN RETURN
3170 IF N<0 OR N>255 OR N<>INT (N) THEN RETURN
3180 IF A>=B THEN RETURN
3190 LET O=1
3200 IF N<>0 THEN LET M=0
3210 IF F<A OR F>=B OR C=0 THEN RETURN
3220 LET P=2^T
3230 IF INT (M/P)-2*INT (M/(2*P))<>0 THEN RETURN
3240 LET M=M+P: LET H=1: RETURN

All state and inputs must be integral bytes, T must be at most seven, and A must be less than B. Invalid input returns H/O=0 without changing M or the other inputs. A valid query returns O=1. With N nonzero it first clears M, even outside the active interval. Clear N after the first query of the new attack, including when processing several targets in one update.

Open the window, then remember

A hit is accepted only when F is at least A and less than B, contact is nonzero, and T is not already in M. H becomes one and that target’s bit is added. A repeated contact returns H=0 while retaining the complete mask. Target IDs must keep their meaning throughout an attack: recycling an ID during the swing needs an explicit policy.

The default caller opens frames two through four. It accepts target one, ignores another contact with that target, then accepts target two. Its mask is six, with bits one and two set. The custom caller opens frames one and two and hits targets seven and zero, producing 129. The saved checks cover both repeat rejection and retention of the earlier target.

Example calls from the maintained caller

70 GOSUB 3000: LET AA=0: LET BB=0
80 LET M=0: LET F=2: LET A=2: LET B=5: LET T=1: LET C=1: LET N=1
90 GOSUB 3100: GOSUB 2000
100 LET F=3: LET N=0
110 GOSUB 3100: GOSUB 2000
120 IF H=0 THEN LET AA=1
130 LET T=2
140 GOSUB 3100: GOSUB 2000
150 IF M=6 THEN LET BB=1
160 LET F=5: LET T=3
170 GOSUB 3100: GOSUB 2000
180 LET F=2: LET T=1: LET N=1
190 GOSUB 3100: GOSUB 2000
200 PRINT "HITW RESULTS";AA;BB
210 ?(MB+995)=AA: ?(MB+996)=BB: ?(MB+997)=GD: ?(MB+998)=WC-256*INT (WC/256): ?(MB+999)=INT (WC/256): ?(MB+1000)=239: STOP

A later query at B is outside the window. Starting a new attack explicitly clears the remembered targets. AA/BB, the boundary table and mailbox belong to the diagnostic. A real game supplies its animation clock and collision results, applies damage when H=1, and keeps M until the next attack. The helper owns neither collision geometry nor damage, animation or time.

Customise the attack

Choose a short active interval for a sharp strike or a longer one for a sweep. Use a different hit mask for each simultaneous attacker. An eight-bit target set keeps the example small; more targets need a wider bitset or a bounded identity list. A byte end frame cannot represent 256. Longer animations need wider frame fields or a documented local phase counter.

Repeated damage from fire or a beam is a different policy: it can use a per-target cooldown rather than a permanent per-attack mark. A contact-pair cache avoids duplicate pair processing during one traversal; this helper deliberately retains hit history across updates.

Mistake and repair

The wrong caller asserts N before every query. That clears the hit set each time: repeated contact hits again and switching targets discards the earlier mark. Both saved checks fail. Assert the reset once when the attack starts, then retain the mask. Repaired source and loaded programs match the normal caller exactly.

Cost and Maths for Games

The query validates seven byte fields and uses powers of two and integer division to inspect a bit without a machine-specific bitwise BASIC operator. There are no arrays or heap allocations in the helper. A machine-code version can use native bit operations; a larger identity list trades memory and search time for more targets and richer identities. No measured cycle budget is inferred.

Maths for Games connects half-open intervals, finite sets and bit masks. The Craft connects active frames, readable anticipation and deliberate hit rules.

Global names and line numbers

BASIC numeric names, arrays and numbered lines are global. To combine helpers, rename public and private fields and renumber the helper together with every GO SUB/GO TO reference. Keep each state block under one owner. The maintained build.py rejects duplicate line numbers; it does not automatically namespace or renumber routines.

Machine and measured size

This helper uses scalar numeric fields and allocates no arrays. Its diagnostic uses MODE 7 and HIMEM=&6000 to separate program storage, mailbox and screen. The helper itself changes neither mode nor HIMEM.

The numbered helper occupies 455 tokenised program bytes on this interpreter, including line headers. This excludes the caller, test tables, numeric scalar/array storage, interpreter stacks and ROM. Tokenised size is not machine-code size or a hardware-cycle count. No real-time or whole-game performance budget is inferred from the diagnostic. The caller’s AA/BB, JJ and RAM mailbox are observation machinery, not required game state.

Execution evidence

Working, custom, deliberately wrong and exact repaired callers executed through BBC Micro’s stock BASIC interpreter under Emu198x 0.44.2. Build198x 0.2.9 tokenises C64 PRG and Spectrum TAP programs. C64 enters stock RUN, Spectrum uses ROM tape loading, and BBC enters every numbered source line through MOS/BASIC. Actual loaded program bytes, complete state packets, positive completion/count/guards and visible result pixels are checked. After the positive completion marker, the observer advances two complete display frames before capturing, so a partially scanned final character cannot masquerade as a finished picture. Firmware is not distributed.

An independent mathematical/order model checks the trace and rejects altered source, configuration, loaded program, state, completion and image evidence. Host exhaustive checks complement the native boundary/sequential examples; those host ranges are not claimed as natively exhaustive. The supplied diagnostic callers deliberately end with STOP; the interpreter report is expected. The wrong caller prints 0,0 and the normal/custom/repaired callers print 1,1.

Public CI checks retained evidence; it does not execute restricted firmware. Refresh with python3 scripts/verify-basic-combat-focus.py attack-hit-window bbc-micro --tools /path/to/extracted/releases and inspect with python3 scripts/check-basic-combat-focus.py attack-hit-window.

Explore further

Compare the assembly technique. The BASIC game-flow routine makes session boundaries explicit. Complete source and native evidence.
