Report Trigger Enter, Stay and Exit Events on Amiga

Standing in a doorway should not count as entering it on every update.

Use it in a project

CURRENT is an eight-bit overlap snapshot, one bit per trigger. Compare it with retained PREVIOUS: ENTERED is current-only, EXITED is previous-only and STAYED is their intersection. Then retain CURRENT as PREVIOUS. Every bit is handled independently; the helper does not decide overlap geometry.

Include component.inc once (MOS callers include the shared 6502 implementation through it). Reserve the public fields in this exact order: ENTERED, STAYED, EXITED, PREVIOUS, CURRENT. They occupy 5 contiguous bytes. Also reserve the private workspace: T0 (1 bytes). Array names in the explanation refer to the numbered consecutive bindings, such as C0, C1 and so on.

Call trigger_transitions_init once at the intended reset boundary. It clears inputs as well as outputs and workspace. Set your starting state and configuration afterwards, then call trigger_transitions_step whenever the described event occurs. The helper reads no device, waits for no frame and installs no interrupt handler.

An intersection reports shared occupancy, while complement-and-intersection picks the two differences. The stored mask turns static collision answers into temporal events.

Reusable initialisation and service

; SPDX-License-Identifier: MIT
; Report Trigger Enter, Stay and Exit Events. See README.md for the byte interface and ownership.
; init clears the public fields and private workspace; set inputs afterwards.
trigger_transitions_init:
    move.b #0,d0
    move.b d0,ENTERED
    move.b d0,STAYED
    move.b d0,EXITED
    move.b d0,PREVIOUS
    move.b d0,CURRENT
    move.b d0,T0
    rts
trigger_transitions_step:
; T0 = PREVIOUS ^ 255
    move.b PREVIOUS,d0
    eor.b #255,d0
    move.b d0,T0
; ENTERED = CURRENT & T0
    move.b CURRENT,d0
    move.b T0,d1
    and.b d1,d0
    move.b d0,ENTERED
; T0 = CURRENT ^ 255
    move.b CURRENT,d0
    eor.b #255,d0
    move.b d0,T0
; EXITED = PREVIOUS & T0
    move.b PREVIOUS,d0
    move.b T0,d1
    and.b d1,d0
    move.b d0,EXITED
; STAYED = CURRENT & PREVIOUS
    move.b CURRENT,d0
    move.b PREVIOUS,d1
    and.b d1,d0
    move.b d0,STAYED
; PREVIOUS = CURRENT
    move.b CURRENT,d0
    move.b d0,PREVIOUS
    rts
component_end:

Machine contract

D0–D3/A0–A1/CCR may change; D4–D7/A2–A6 are preserved. A direct BSR/JSR needs four return-address stack bytes. The helper makes no nested calls and adds no other stack use. Its named scratch is private workspace, not a pointer, a ROM variable or shared zero-page space that the game may borrow concurrently. The samples use fixed symbol bindings. Scope or rename every label and binding, including the component_end measurement marker, and allocate a separate block for each independent instance. Different helpers can also use common field names, so combining them needs separate namespaces or explicitly renamed bindings. Give each block one mutation owner.

The A500 OCS diagnostic cold-boots an OFS disk, owns the Copper and bitplane and disables interrupt/DMA sources. The helper does not take over hardware or allocate Chip RAM.

Adapt the caller

demo.asm supplies the bindings and include order. exercise.inc first runs table cases, then a separate client retaining state between calls. A game can call the public step entry directly and remove the diagnostic packet and display. Do not copy the diagnostic’s hardware takeover into an existing game loop.

Build with make ASM198X=/path/to/asm198x and BUILD198X=/path/to/build198x. The Makefile produces normal, custom, deliberately wrong and repaired programs. Tools must already be installed; the sample downloads nothing.

Bindings and include order

    section code,code_c
CUSTOM = 0
BROKEN = 0
COYOTE_STEPS = 4
BUFFER_STEPS = 4
TEXT_CAP = 8
PROPERTY_COUNT = 16
STREAM_BYTES = 13
CRC_POLY = 7
    include "caller.inc"
    include "exercise.inc"
component_start:
    include "component.inc"
    even
    include "data.inc"
    include "cases.inc"
    even
    include "display.inc"
    include "../../framework/turn-deadline/font.inc"
code_end:
STATE:
ENTERED: dc.b 0
STAYED: dc.b 0
EXITED: dc.b 0
PREVIOUS: dc.b 0
CURRENT: dc.b 0
T0: dc.b 0
    even
ready: dc.w 0
preview: dcb.b 8,0
OUTPUT: dcb.b 1300,0
    even
signature: dc.b "198XWORLDKIT000",0
    even
copperlist:
    dc.w $08e,$2c81,$090,$2cc1,$092,$0038,$094,$00d0
    dc.w $100,$1200,$102,0,$104,0,$108,0,$10a,0
    dc.w $180,$012,$182,$fff
copbpl:
    dc.w $0e0,0,$0e2,0
    dc.w $ffff,$fffe
plane: dcb.b 10240,0

A client retaining state between calls

preview_rules:
    ifne CUSTOM
; CURRENT = 128
    move.b #128,d0
    move.b d0,CURRENT
    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state
; CURRENT = 0
    move.b #0,d0
    move.b d0,CURRENT
    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state
; CURRENT = 128
    move.b #128,d0
    move.b d0,CURRENT
    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state
    rts
    else
; CURRENT = 3
    move.b #3,d0
    move.b d0,CURRENT
    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state
; CURRENT = 6
    move.b #6,d0
    move.b d0,CURRENT
    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state

    ifne BROKEN
; PREVIOUS = 0
    move.b #0,d0
    move.b d0,PREVIOUS
    endif
    bsr checked_step
    bsr emit_state
    endif
    rts

Customise it

Use the high trigger bit and an exit/re-entry sequence. The maintained custom caller changes its inputs or client sequence rather than hiding a different implementation behind the same label. Compare every state of the two clients, not only their final display.

Custom client selection

    section code,code_c
CUSTOM = 1
BROKEN = 0
COYOTE_STEPS = 2
BUFFER_STEPS = 2
TEXT_CAP = 4
PROPERTY_COUNT = 16
STREAM_BYTES = 13
CRC_POLY = 49
    include "caller.inc"
    include "exercise.inc"
component_start:
    include "component.inc"
    even
    include "data.inc"
    include "cases.inc"
    even
    include "display.inc"
    include "../../framework/turn-deadline/font.inc"
code_end:
STATE:
ENTERED: dc.b 0
STAYED: dc.b 0
EXITED: dc.b 0
PREVIOUS: dc.b 0
CURRENT: dc.b 0
T0: dc.b 0
    even
ready: dc.w 0
preview: dcb.b 8,0
OUTPUT: dcb.b 1300,0
    even
signature: dc.b "198XWORLDKIT000",0
    even
copperlist:
    dc.w $08e,$2c81,$090,$2cc1,$092,$0038,$094,$00d0
    dc.w $100,$1200,$102,0,$104,0,$108,0,$10a,0
    dc.w $180,$012,$182,$fff
copbpl:
    dc.w $0e0,0,$0e2,0
    dc.w $ffff,$fffe
plane: dcb.b 10240,0

The custom diagnostic row is 80 00 00 80 80 00 00 00. The full client trace in the source explains how it gets there.

Mistake and repair

The wrong caller clears PREVIOUS each time. Occupied triggers keep re-entering and exit events disappear. Retain the last complete snapshot for this same actor.

The BROKEN branch lives in the sequential client, not the reusable helper. wrong.asm selects it; repaired.asm restores the normal call sequence. The repaired executable matches the normal program (for Spectrum, compare loaded CODE rather than the tape filename).

Select the deliberately wrong client

    section code,code_c
CUSTOM = 0
BROKEN = 1
COYOTE_STEPS = 4
BUFFER_STEPS = 4
TEXT_CAP = 8
PROPERTY_COUNT = 16
STREAM_BYTES = 13
CRC_POLY = 7
    include "caller.inc"
    include "exercise.inc"
component_start:
    include "component.inc"
    even
    include "data.inc"
    include "cases.inc"
    even
    include "display.inc"
    include "../../framework/turn-deadline/font.inc"
code_end:
STATE:
ENTERED: dc.b 0
STAYED: dc.b 0
EXITED: dc.b 0
PREVIOUS: dc.b 0
CURRENT: dc.b 0
T0: dc.b 0
    even
ready: dc.w 0
preview: dcb.b 8,0
OUTPUT: dcb.b 1300,0
    even
signature: dc.b "198XWORLDKIT000",0
    even
copperlist:
    dc.w $08e,$2c81,$090,$2cc1,$092,$0038,$094,$00d0
    dc.w $100,$1200,$102,0,$104,0,$108,0,$10a,0
    dc.w $180,$012,$182,$fff
copbpl:
    dc.w $0e0,0,$0e2,0
    dc.w $ffff,$fffe
plane: dcb.b 10240,0

Cost and alternatives

The measured helper extent is 130 code bytes; public state is 5 bytes and private scratch is 1 bytes. There are no immutable helper tables. Caller data, the test cases, return-address stack, alignment and display buffers cost additional space. These are assembled sizes, not cycle measurements.

Constant work for eight zones in one byte. More triggers can use more mask bytes or a sparse event list; neither removes the need to own the previous state per actor.

Snapshots can miss a fast pass through a narrow zone between updates. Swept geometry or substeps may be needed. Separate actors need separate previous masks; combining their snapshots changes the meaning of an event.
