Draw a life bar, outline a room or inspect one dot before deciding where a bullet lands. These are six callable routines for a bitmap you own. Use a point when you need one pixel; use a span or box when that is the job, so the machine does not calculate every address again.
Include it, then draw a box
Reserve 48 bytes at BP, even-aligned at $2000. Define PIXEL_WIDTH/HEIGHT as 320/256, and BITMAP_BASE as $10000. Include m68000.inc once. Code, stack, tables, BP and the bitmap must not alias. Scratch needs no initialisation; public request fields do.
After the named display setup, this is a normal direct call. The excerpt stops before the diagnostic marker/mailbox; your game does not need those stores.
Outline [13,91) across and [27,53) down
; A normal game call: outline a box. End coordinates are exclusive.
move.w #13,BP
move.w #27,BP+2
move.w #91,BP+4
move.w #53,BP+6
clr.b BP+8
bsr bp_boxRead BP+9: one means accepted, zero rejected. Change the fields and call again. There is no retained drawing list or game loop inside the component.
The calling contract
Words use big-endian order. Origin is top left, Y downwards. Call bp_pixel, bp_read, bp_hspan, bp_vspan, bp_fill or bp_box.
| BP offset | Supply or read |
|---|---|
| 0,2 | Unsigned x0,y0 words |
| 4,6 | Exclusive x1,y1 words |
| 8 | Operation 0 set, 1 clear, 2 XOR; read requires 0 |
| 9 | Accepted 1, rejected 0 |
| 10 | Stored read bit 0/1; otherwise 0 |
| 11 | Ignored and preserved |
| 12–39,42–47 | Private scratch |
| 40 | Output word: destination-byte stores |
Pixel/read ignore both ends; hspan ignores y1; vspan ignores x1. Fill and box use [x0,x1)×[y0,y1). A box [5,13)×[20,24) is eight pixels wide and four high. The effective rectangle must be ordered, nonempty and inside 320×256; invalid requests reject before destination writes, with zero read/write outputs. Public inputs 0–8 and 11 survive.
This is strict rejection rather than clipping. Intersect with your display before calling if you want partially visible shapes. An outline visits a shared corner once, including a 1×1 box; XOR therefore leaves its corner visible instead of toggling it twice.
One Chip RAM plane, with arbitrary pixel edges
This A500 PAL caller supplies a 320×256 low-resolution plane at $10000–$127FF, a 72-byte Copper list at $4000, zero modulos and a black/white palette. The plane takes 10,240 bytes. Display DMA reads Chip RAM; pointing it at CPU-accessible Fast RAM would not provide a valid A500 display.
address = $10000 + y*40 + (x div 8)
At (13,20), that is $10321, mask $04. The CPU derives one row address and walks byte masks. Arbitrary X values work without making the caller align an edge to a word. There are no scanline tables here.
This backend owns one stored bit per pixel. More planes need a deliberate plane/pen adapter and ownership policy. The caller owns the Copper, plane pointers, palette, DMA and interrupt policy. It is an original reset ROM, not Kickstart or an AmigaOS display setup. Do not let a blitter operation or IRQ renderer race a CPU read/modify/write call.
Word or longword interiors could reduce the CPU store count when alignment permits. The CPU/blitter region example shows an aligned two-plane alternative with its own masks, modulos, ownership and completion checks. That does not supply general arbitrary-position blitter spans. The current backend is a clear CPU baseline you can measure and replace where your game needs more.
Division chooses a byte; remainder chooses a bit
At X13, 13 div 8 = 1 picks byte-column one and 13 mod 8 = 5 picks its sixth pixel. With bit 7 leftmost, 128 >> 5 = 4. OR sets the mask, AND with its inverse clears it, and XOR toggles it. Replacing the byte with just $04 would erase seven neighbours.
Place a point explains the origin and local/screen distinction. Draw with integer error shows how points and spans build curves. A qualified primitive does not automatically qualify those higher-level adapters on this display; their machine entries name their own evidence.
Open the reusable m68k backend
Include the maintained backend once
; SPDX-License-Identifier: MIT
; One selected 320-wide Chip RAM plane; byte spans, native big-endian BP words.
; BP: 48 even-aligned private RAM bytes. BITMAP_BASE and PIXEL_WIDTH/HEIGHT are constants.
; Public +0/2 x0/y0, +4/6 exclusive x1/y1, +8 op0=set/1=clear/2=XOR.
; Outputs +9 accepted, +10 stored read bit, +40 word destination-byte stores.
; Inputs +0..8 and +11 survive. D0-D7/A1/CCR destroyed; SR interrupt bits unchanged.
; CPU owns this plane during a call: no blitter, Copper pointer change or IRQ writer.
bp_fill:
moveq #0,d0
bra bp_enter
bp_box:
moveq #1,d0
bra bp_enter
bp_pixel:
moveq #2,d0
bra bp_enter
bp_read:
moveq #3,d0
bra bp_enter
bp_hspan:
moveq #4,d0
bra bp_enter
bp_vspan:
moveq #5,d0
bp_enter:
move.b d0,BP+12
clr.b BP+9
clr.b BP+10
clr.w BP+40
move.l BP,BP+16
move.l BP+4,BP+20
cmp.b #2,d0
blo bp_validate
cmp.b #5,d0
beq bp_unit_x
move.w BP+18,d1
addq.w #1,d1
move.w d1,BP+22
cmp.b #4,d0
beq bp_validate
bp_unit_x:
move.w BP+16,d1
addq.w #1,d1
move.w d1,BP+20
bp_validate:
cmp.b #3,BP+8
bhs bp_invalid
cmp.b #3,BP+12
bne bp_bounds
tst.b BP+8
bne bp_invalid
bp_bounds:
move.w BP+16,d0
cmp.w BP+20,d0
bhs bp_invalid
cmp.w #PIXEL_WIDTH,BP+20
bhi bp_invalid
move.w BP+18,d0
cmp.w BP+22,d0
bhs bp_invalid
cmp.w #PIXEL_HEIGHT,BP+22
bhi bp_invalid
move.b #1,BP+9
move.w BP+16,d2
lsr.w #3,d2
move.w BP+20,d3
subq.w #1,d3
lsr.w #3,d3
move.w BP+16,d1
and.w #7,d1
move.w #$ff,d6
lsr.w d1,d6
move.w BP+20,d1
subq.w #1,d1
and.w #7,d1
moveq #7,d0
sub.w d1,d0
move.w #$ff,d7
lsl.w d0,d7
move.w BP+18,d4
bp_row:
move.w d4,d0
mulu.w #40,d0
lea BITMAP_BASE,a1
adda.l d0,a1
adda.w d2,a1
move.w d2,d5
bp_byte:
move.w #$ff,d0
cmp.w d2,d5
bne bp_not_left
and.w d6,d0
bp_not_left:
cmp.w d3,d5
bne bp_not_right
and.w d7,d0
bp_not_right:
cmp.b #1,BP+12
bne bp_apply
cmp.w BP+18,d4
beq bp_apply
move.w BP+22,d1
subq.w #1,d1
cmp.w d1,d4
beq bp_apply
moveq #0,d0
cmp.w d2,d5
bne bp_box_right
move.w BP+16,d1
and.w #7,d1
move.w #$80,d0
lsr.w d1,d0
bp_box_right:
cmp.w d3,d5
bne bp_apply
move.w BP+20,d1
subq.w #1,d1
and.w #7,d1
move.w d0,BP+44
move.w #$80,d0
lsr.w d1,d0
or.w BP+44,d0
bp_apply:
tst.b d0
beq bp_advance
cmp.b #3,BP+12
bne bp_draw
and.b (a1),d0
beq bp_invalid
move.b #1,BP+10
rts
bp_draw:
cmp.b #1,BP+8
beq bp_clear
cmp.b #2,BP+8
beq bp_xor
or.b d0,(a1)
bra bp_count
bp_clear:
not.b d0
and.b d0,(a1)
bra bp_count
bp_xor:
eor.b d0,(a1)
bp_count:
addq.w #1,BP+40
bp_advance:
addq.l #1,a1
addq.w #1,d5
cmp.w d3,d5
bls bp_byte
addq.w #1,d4
cmp.w BP+22,d4
blo bp_row
bp_invalid:
rtsWhat it costs, and what to try next
A 32×8 fill takes 32 byte stores at X24 and 40 at X25 on this backend. Full-display fills take 10,240 stores. Spans protect their two edges and write full interior bytes, avoiding repeated per-pixel work. These are observed destination stores, not elapsed cycles or a frame-budget promise.
The backend assembles to 480 bytes, plus the 72-byte Copper list and the 48-byte context. Reset setup, bitmap, stack and assets are additional. Byte masks make edge ownership simple; wider interior stores or DMA need separate alignment and ownership work. A character-backed or sprite display may fit a game’s actual job better than painting bitmap shapes.
Clobbers D0–D7/A1/CCR; SR interrupt-mask bits survive. Reserve a conservative 64-byte stack budget beyond your other calls/IRQs. BP is non-re-entrant. The routine changes no interrupt enables, acquires no OS display and synchronises no video access. Your caller owns that integration.
What was verified
173 calls completed using Asm198x 0.0.71 and native Emu198x 0.39.0 in the stated original reset configuration. Every call compares the complete bitmap allocation, guards, public inputs, acceptance/read and byte-store counts with an independent selected-pixel model. Cases cover every horizontal phase, set/clear/XOR/read, tiny and full rectangles, last pixels, row boundaries, rejected declarations and aligned/unaligned fills. Selected whole native frames match independently composed images.
The Copper list is checked unchanged. Wrong-mask and wrong-row executables each complete accepted calls and fail both memory and picture checks. Retained records bind exact source/tools and have evidence-corruption failure tests. Stock-OS loading, original-hardware timing and tear-free coexistence remain separate checks.
