Change Shared Character Pictures on Jupiter Ace

A wall can appear in twenty places while its picture is stored once. Change that picture and every wall changes. Open one door instead, and you probably want to change just that cell’s number. These routines let you choose.

Include, initialise and call

Reserve 24 private RAM bytes at G and include glyphs.inc. The original caller uses the base RAM at G=$3C40, source $3D00 and stack $3FF0. It disables interrupts and takes over the display; it does not run inside Forth. Forth normally owns these workspaces and the character set, so a Forth-callable wrapper needs its own agreement about stacks, memory and interrupts.

Include the maintained character component

kernel_start:
    include "glyphs.inc"

glyph_init clears the owned pictures and names. That destroys their old contents, so use it during setup. Then install two original sketches and select the first twice:

Initialise, install and select shared pictures

    call glyph_init
example_install:
    ld hl,original_patterns
    ld (G),hl
    ld a,1
    ld (G+2),a
    ld a,2
    ld (G+3),a
    call glyph_install
    ld a,1
    ld (G+4),a
    ld hl,66
    ld (G+5),hl
    call glyph_select
    ld hl,67
    ld (G+5),hl
    call glyph_select

Your game calls these entries directly. The later mailbox and debugger readbacks are optional verification transport.

Supply a source, slot and cell

All words are little-endian. glyph_install uploads a range; glyph_replace uploads one shape and ignores count; glyph_select writes one cell’s screen code. Init clears the owned allocations. Inputs 0–6 survive, and status/write count reset even when a request rejects.

Stored shapes are 0–127, counts 1–128 with first+count <= 128. Screen codes are 0–255: the low seven bits select a shape, and bit 7 selects inverse video. Code 128 is not a 129th stored shape. Logical cells are 0–767.

Zero counts, overflowing ranges and invalid slots/cells reject before a destination write. Keep the source long enough, readable, non-wrapping, stable and separate from the context/destination. These are trusted pointers, not an arbitrary-memory validator.

The context is non-re-entrant. AF/BC/DE/HL and flags are clobbered; reserve eight stack bytes including the direct call. Add space for your own calls and interrupts. The routines do not change interrupt state or banks.

Respect the machine’s characters

The Ace has 32×24 cells and 128 writable 8×8 shapes. The routine writes pictures through $2C00–$2FFF and names through $2400–$26FF, using the TV-priority aliases. The lower mirrors at $2800/$2000 give the CPU priority instead, with different display contention. Choosing an address is therefore a hardware access policy, not just a way of saving a byte.

Character RAM is hardware write-only. Keep the source pictures in readable RAM or ROM. If you want to change one row, change your source copy and upload it; do not read-modify-write character RAM. The diagnostic uses debugger inspection to check the stored shapes. That does not give a game a CPU font-read API.

Normal glyph bits are white on black; code+128 swaps them. Each row stores eight dots, bit 7 on the left. Slot 127 starts at $2C00+127*8 = $2FF8. The screen code 255 shows its inverse, using exactly the same eight stored bytes. Replacing that slot changes both its normal and inverse instances.

The caller preserves the 256 name-padding/workspace bytes and a working-RAM guard. Taking over those allocations is not proof of safe coexistence with the Forth input buffer, frame interrupt or dictionary.

Count a shape and its place

Cell (2,2) has index 2*32+2 = 66. Local dot (3,5) reaches active pixel (2*8+3, 2*8+5) = (19,21). The native capture also has a border; those border pixels do not belong to the character grid.

Move a glyph connects bit weights, stored shapes, codes and cell placement. Place a point explains local and screen coordinates. These routines place fixed-grid pictures; they do not implement proportional text, arbitrary placement or scaled letters.

Replace the shared picture, or one instance

After the example, point G+0 at a new eight-row sketch, set G+2 to 1 and call glyph_replace. Both cells still use that slot, so both change. To change only the first, put code 2 in G+4 and its logical cell index in G+5, then call glyph_select. The second keeps the old code.

; SPDX-License-Identifier: MIT
; Ace 128 writable glyphs at TV-priority $2C00; names $2400, 32x24.
; G=24 private RAM bytes. LE source +0, first +2, count +3, screen code +4,
; cell word +5, output accepted +7, output data-write word +8, scratch +10..23.
; Inputs +0..6 survive. AF/BC/DE/HL/flags clobbered; non-reentrant.
; Caller owns Forth/interrupt/RAM allocation. Font is hardware write-only:
; keep the source in readable CPU RAM/ROM, never read-modify-write character RAM.
glyph_init:
    call glyph_reset_result
    ld de,$2c00
    ld bc,1024
    call glyph_zero
    ld de,$2400
    ld bc,768
    call glyph_zero
    jp glyph_accept
glyph_zero:
    xor a
    call glyph_store
    dec bc
    ld a,b
    or c
    jr nz,glyph_zero
    ret
glyph_replace:
    ld a,1
    jr glyph_begin
glyph_install:
    ld a,(G+3)
glyph_begin:
    ld (G+10),a
    call glyph_reset_result
    ld a,(G+10)
    or a
    ret z
    ld b,a
    ld a,(G+2)
    cp 128
    ret nc
    add a,b
    ret c
    cp 129
    ret nc
    ld a,(G+2)
    ld l,a
    ld h,0
    add hl,hl
    add hl,hl
    add hl,hl
    ld de,$2c00
    add hl,de
    ex de,hl
    ld a,(G+10)
    ld l,a
    ld h,0
    add hl,hl
    add hl,hl
    add hl,hl
    ld b,h
    ld c,l
    ld hl,(G)
glyph_copy:
    ld a,(hl)
    call glyph_store
    inc hl
    dec bc
    ld a,b
    or c
    jr nz,glyph_copy
glyph_accept:
    ld a,1
    ld (G+7),a
    ret
glyph_select:
    call glyph_reset_result
    ld hl,(G+5)
    ld de,768
    or a
    sbc hl,de
    ret nc
    ld hl,(G+5)
    ld de,$2400
    add hl,de
    ex de,hl
    ld a,(G+4)
    call glyph_store
    jp glyph_accept
glyph_reset_result:
    xor a
    ld (G+7),a
    ld (G+8),a
    ld (G+9),a
    ret
glyph_store:
    ld (de),a
    inc de
    push hl
    ld hl,(G+8)
    inc hl
    ld (G+8),hl
    pop hl
    ret

Pay for what changes

One cell selection writes one name byte. Replacing one picture writes eight bytes, regardless of how many cells use it. Full init writes 1,792 bytes. The assembled component uses 161 code bytes, 24 context bytes and eight source bytes per picture, excluding reset/video/diagnostic code.

Choose the operation by what should change. Eight writes can update many shared walls, but one write can open one door. These are storage and destination-write counts, not elapsed time. A font bank or cache can spend memory to avoid regenerating pictures. Live upload scheduling and physical contention need their own measurements before claiming a frame budget.

What was verified

21 calls completed per build, using Asm198x 0.0.71. The released Emu198x 0.41.0 core had the normal/inverse colours reversed. Qualification here uses the corrected Ace source build, pinned to commit 7806827f35d4f49417f3cbfd537470f1a91f06b4 with executable and Cargo.lock hashes. A source-independent regression fails on the old mapping and passes with the correction. The reusable component only writes font memory; it does not depend on the emulator’s readable-font simplification.

Three builds on each of the three targets produce 210 executed calls in total. Tests include shared replacement, one-cell selection, inverse forms, full legal uploads, final slots/cells, zero/overflow requests and reset. Completed wrong-slot and wrong-name controls fail both memory and visible-output checks. Selected whole native frames match an independent compositor; retained checks reject missing calls and rehashed wrong observations.

These original reset callers do not establish stock-OS loading, interrupt coexistence, physical timing or tear-free updates. Code and original pictures are MIT licensed.
